23 TECHNICAL DATA
144
23.2 Engine tightening torques
Oil jet, piston cooling M4 2 Nm (1.5 lbf ft)
Loctite
®
243™
Oil nozzle for clutch lubrication M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Oil nozzle, piston cooling M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Oil nozzle, rocker arm lubrication M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Pulse generator screw and cable
retainer
M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, bearing retainer M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, clutch spring retainer M5 6 Nm (4.4 lbf ft)
Screw, gear position sensor M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, locking lever M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, stator M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, suction pump cover M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Nut, water pump impeller M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, alternator cover M6 10 Nm (7.4 lbf ft)
Screw, bearing bolt, torque limiter M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, camshaft support plate M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, clutch cover M6 10 Nm (7.4 lbf ft)
Screw, cylinder head M6 10 Nm (7.4 lbf ft)
Screw, engine case M6 10 Nm (7.4 lbf ft)
Screw, EVAP plug M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, exhaust flange M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, idler M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, oil filter cover M6 10 Nm (7.4 lbf ft)
Screw, pressure pump cover M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift drum locating M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft)
Screw, timing chain securing
guide
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
