12 SERVICE WORK ON THE CHASSIS
71
F01027-01
Main work
– Wash the air filter thoroughly in special cleaning liquid and
allow it to dry properly.
Air filter cleaning agent ( p. 153)
Info
Only press the air filter to dry it, never wring it out.
– Oil the dry air filter with a high quality filter oil.
Oil for foam air filter ( p. 153)
– Clean the air filter box.
– Check the intake flange for damage and looseness.
Finishing work
– Install the air filter. ( p. 70)
– Install the air filter box cover. ( p. 69)
12.25 Sealing the air filter box
Preparatory work
– Remove the air filter box cover. ( p. 69)
F00248-01
Main work
–
Seal the air filter box in the marked area
A
.
Finishing work
– Install the air filter box cover. ( p. 69)
12.26 Removing the right side cover
E00942-10
–
Remove screw
1
.
–
Pull off the side cover sideways in areas
A
and
B
, and
remove toward the front.
