23 TECHNICAL DATA
148
Weight of rider: 65 … 75 kg (143 … 165 lb.) 4.4 N/mm (25.1 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 4.6 N/mm (26.3 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 4.8 N/mm (27.4 lb/in)
Fork length 928 mm (36.54 in)
Fork oil per fork leg 635±10 ml (21.47±0.34 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 151)
23.8 Shock absorber
Shock absorber article number 18.15.7R.69
Shock absorber WP Performance Systems 5018 DCC Link
Compression damping, low-speed
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Compression damping, high-speed
Comfort 2.5 turns
Standard 2 turns
Sport 1.5 turns
Rebound damping
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Spring preload 14 mm (0.55 in)
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 45 N/mm (257 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 48 N/mm (274 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 51 N/mm (291 lb/in)
Spring length 260 mm (10.24 in)
Gas pressure 10 bar (145 psi)
Static sag 35 mm (1.38 in)
Riding sag 110 mm (4.33 in)
Fitted length 477 mm (18.78 in)
Shock absorber oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 152)
23.9 Chassis tightening torques
Remaining screws, chassis EJOT PT
®
K60x25‑Z 2 Nm (1.5 lbf ft)
Screw, active carbon filter - 5 Nm (3.7 lbf ft)
Screw, intake air temperature sen-
sor
EJOT PT
®
K50x18 2 Nm (1.5 lbf ft)
Screw, pressure regulator EJOT PT
®
K60x25‑Z 3.5 Nm (2.58 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
