Hypertherm HyPerformance HPR130XD User Manual

Appendix B – CnC interfACe protoCol
b-8 HPR130XD Auto Gas – 806330 Revision 1
Command table (3 of 14)
ID Command System Description
068
SYSTEM_RESET Manual gas system
Auto gas system
Clear error conditions and resume operation. Only accepted
if system is in a shutdown error condition (Error code > 79
and State = 14).
Data:
None
Return value:
1 = accepted, 0 = not accepted
Sample:
>0689E<
>0681CF<
070
SET_CORNER_CURRENT Manual gas system
Auto gas system
When CORNER CURRENT input is activated the power
supply will switch to the current percentage specified.
Data:
% of cutting current (50-100%)
50=50%
Return value:
% achieved
Sample:
>0707503<
>070007563< (set 75%)<
071
MANUAL_PUMP_CONTROL Manual gas system
Auto gas system
Used to override software control of the coolant pump. If the
system has a fatal error, the pump cannot be overridden.
Data:
1 = override software to force pump on, 0 = system software
controls the pump, override off
Return value:
1 = accepted, 0 = not accepted
Sample:
>0711C9<
>0711C9<
072
GET_CONTROL_VOLTAGE Manual gas system
Auto gas system
Returns the internal control voltage of the power supply
Data:
None
Return value:
Voltage (1/10 V)
1200 = 120.0 V
Sample:
>07299<
>07212005C< (120.0 volts)
