POWER SUPPLY SETUP
powermax 45 Operator Manual 2-5
Power cord considerations
Powermax45 power supplies are shipped with CSA and CE power cord configurations.
The power cords on the CSA power supplies are shipped with a 50 A, 250 V plug (NEMA 6-50P)
on the power cord.
The CE power supplies are shipped without a plug on the power cord. Obtain the correct plug for
your unit (either 230 V or 400 V) and location have it installed by a licensed electrician.
Extension cord recommendations
Any extension cord must have an appropriate wire size for the cord length and system voltage.
Usea cord that meets national and local codes.
The tables on the next page provides the recommended gauge size for various lengths and input
voltages. The lengths in the tables are the length of the extension cord only; they do not include
the power supply’s power cord.
