Replacing or Installing a Disk Drive Bezel onto a Disk Drive
To replace or install a disk drive bezel onto a disk drive or filler, do the following:
1. Remove the disk drive filler panel from the slot you want to use by pressing the filler release tab
located at the top front edge of the filler panel and pulling the filler out of the system.
2. Remove the disk drive bezel plug from the front of the filler panel.
3. Remove the disk drive bezel from the front edge of the filler panel.
4. Attach the disk drive bezel to the front of the disk drive.
5. Follow the procedures for adding a disk drive as described in “Hot-Swap Disk Drives” on page 333.
2
1
1 Disk Drive Bezel 2 Disk Drive
332 EserverpSeries 615 Service Guide
