17
3
MEMORY OPERATION
03
■ GPS memory
When connected to an external GPS receiver* equipped with
an airport frequency database, frequency data such as
nearby airports can be transferred and made available in the
GPS memory (maximum 10-memory channels).
*Ask your dealer for available GPS receiver details.
q Push [RCL] to enter the memory mode.
•The channel number appears.
w Rotate [O-DIAL] to select the GPS memory channel.
•“GPS” appears.
e Rotate [DIAL] to select a desired channel.
r Push [RCL] to exit the GPS memory mode.
■ Weather memory channel
(U.S.A. version only)
The U.S.A. version has VHF marine WX (weather) channel
receiving capability for flight planning.
q Push [RCL] to enter the memory mode.
•The channel number appears.
w Rotate [O-DIAL] to select the weather memory channel.
•“WEATHER” appears.
e Rotate [DIAL] to select a desired channel.
r Push [RCL] to exit the weather memory mode.
Channel Frequency Channel Frequency
WX01 162.550 MHz WX06 162.500 MHz
WX02 162.400 MHz WX07 162.525 MHz
WX03 162.475 MHz WX08 161.650 MHz
WX04 162.425 MHz WX09 161.775 MHz
WX05 162.450 MHz WX10 163.275 MHz
• Weather memory channel list
NOTE: See the GPS receiver’s instruction manual when
transferring the frequency data in details.
