30
8
SPECIFICATIONS
D General
•Frequency range : 118.000 to 136.975 MHz
161.650 to 163.275 MHz*
•Channel spacing : 25 kHz
•Frequency stability :±5 ppm
•Operating temperature : –20˚C to +55˚C
–4˚F to +131˚F
•Antenna impedance : 50 Ω
•Number of memory channels : 10 memory channels
200 group channels
10 history channels
10 GPS channels
10 weather channels*
•Mode : AM (6K00A3E)
•Power supply requirement : 13.80 V / 27.50 V DC
(negative ground)
•Dimensions : 160 (W)✕ 34 (H) ✕ 271 (D) mm
(projections not incl.)
6
5
/
16
(W)✕ 1
11
/
32
(H)✕ 10
21
/
32
(D)
in
•Weight : approx 1.0 kg; 2.2 lb
*U.S.A. version only, receiving only.
D Transmitter
•Mode : A3E
•Output power : 8 W (Carrier power)
•Spurious emissions : –60 dBc
•Microphone impedance : 600 Ω
•Modulation limiting : 70% (Max 98%)
D Receiver
•Receive system : Double conversion
superheterodyne
•Intermediate frequencies : 1st 38.85 MHz
2nd 450 kHz
•Sensitivity : (AM) Less than 2 µV (pd)
at 6 dB S/N
(FM) Less than 1.4 µV
at 12 dB SINAD*
•Selectivity :6 dB ±3 kHz
60 dB ±22 kHz
•Spurious response rejc. : More than 74 dBµ
•Audio output power : 5 W with a 4 Ω load (External
speaker)
60 mW with a 500 Ω load
(Headphone)
Measurements made in accordance with RTCA DO-186B for
U.S.A. version. All stated specifications are subject to change
without notice or obligation.
