17
3
CONVENTIONAL OPERATION
D DTMF transmission
If the transceiver has [DTMF Autodial] assigned to it, the automatic
DTMF transmission function is available. Up to 8 DTMF channels
are available.
TO SELECT A TX CODE:
q Push [DTMF Autodial]— a DTMF channel appears.
w Push [ ]/[ ] to select the desired DTMF channel.
e Push [DTMF Autodial] to transmit the DTMF code in the selected
DTMF channel.
■ Scrambler function
The voice scrambler function provides private communication be-
tween stations. The frequency inversion type is equipped to all ver-
sions, and some versions have the Rolling or Non-rolling type
installed.
q Push [Scrambler] to turn the scrambler function ON.
w “ ” appears.
e Push [Scrambler] again to turn the scrambler function OFF.
IC-F50_F60_MDC-2.qxd 06.11.17 4:39 PM Page 17 (1,1)
