46
6
BATTERY CHARGING
6
■ Optional battery chargers
ï Regular charging with the BC-152
q Attach the BC-152 to a flat surface, such as a desk, if desired.
w Connect the AC adapter (BC-147A/E*) as shown below.
*Depending on version.
e Insert the battery pack with/without the transceiver into the
charger.
• The charge indicator lights green.
r Charge the battery pack approx. 9–10 hours, depending on the
remaining power condition.
• The charge indicator goes off when charging is complete.
Charge indica-
tor lights green
while charging.
AC adapter
BC-152
Battery pack
Transceiver
Supplied screws
Ensure the guide lobs
on the battery pack are
correctly aligned with
the guide rails inside
the charger adapter.
Lobs
Guide rails
Turn power OFF
IC-F50_F60_MDC-2.qxd 06.11.17 4:39 PM Page 46 (1,1)
