54
7
SPEAKER-MICROPHONE
■ Attachment
Attach the connector of the speaker-microphone into the [SP MIC]
connector on the transceiver and tighten the screw.
IMPORTANT: KEEP the [SP MIC] jack cover attached (trans-
ceiver) when the speaker-microphone is not in use. Water will
not get into the transceiver even if the cover is not attached,
however, the terminals (pins) will become rusty, or the trans-
ceiver will function abnormally if the connector becomes wet.
CAUTION: Attach the
speaker-microphone s
connector securely to pre-
vent accidental dropping,
or water intrusion in the
connector.
7
IC-F50_F60_MDC-2.qxd 06.11.17 4:39 PM Page 54 (1,1)
