Band edge frequency setting D
Command: 02
q
X
w ertyuio!0!1
XXXXXXX X2 00 DXXXXXXXX X
10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–9 1 MHz digit: 0–9 1000 MHz digit: 0 (fixed) 100 MHz digit: 0–9 10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–9 1 MHz digit: 0–9 1000 MHz digit: 0 (fixed) 100 MHz digit: 0–9 Separator (fixed)
Lower edge Upper edge
Operating frequency D
Command: 03, 1A 35
q
XXXXX
we
X
rt
XX 00
10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–9 1 MHz digit: 0–9 1000 MHz digit: 0 (Fixed) 100 MHz digit: 0 (Fixed)
Audio volume level D
Command: 14 01
Data VR level Data VR level Data VR level
00 00 0 01 89 17 02 23 34
01 39 1 01 91 18 02 25 35
01 43 2 01 93 19 02 27 36
01 47 3 01 95 20 02 29 37
01 51 4 01 97 21 02 31 38
01 55 5 01 99 22 02 33 39
01 59 6 02 01 23 02 35 40
01 63 7 02 03 24 02 37 41
01 67 8 02 05 25 02 39 42
01 71 9 02 07 26 02 41 43
01 75 10 02 09 27 02 43 44
01 77 11 02 11 28 02 45 45
01 79 12 02 13 29 02 47 46
01 81 13 02 15 30 02 49 47
01 83 14 02 17 31 02 51 48
01 85 15 02 19 32 02 53 49
01 87 16 02 21 33 02 55 50
ALE setting D
Command: 1A 41
q: Call type
…… ……
w: Individual ID or NET ID
r: Message
e: Separator (0×2C)
XXXX XXXXXX XX
Call type data q
Call type
q Data
Separator Message
Individual 00 — —
NET 01
✔
—
Individual AMD 02
✔ ✔
NET AMD 03
✔ ✔
Sounding 04 — —
Individual Update LQA 05 — —
NET Update LQA 06
✔
—
Unlink Individual AMD 07
✔ ✔
Unlink NET AMD 08
✔ ✔
Individual ID or NET ID w
1 to 15 characters
Basic 38 ASCII subset (‘A’ to ‘Z,’ ‘0’ to ‘9,’ ‘@,’ ‘?’)
Character ASCII code Character ASCII code
0–9 30–39 A–Z 41–5A
@ 40 ? 3F
Message r
1 to 90 characters
ASCII code (20 to 5Fh)
Data content description
