Icom IC-F8101 Instruction Manual

85
6
CONNECTION AND INSTALLATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Quick Reference
Pin Pin name Pin
15
69
1 NC —
2 GPS RX 5
3 NC —
4 NC —
5 GND 12
6 NC —
D-sub 9 pin
(Male)
7 NC —
15
11
6
15
10
8 NC —
9 NC —
15
69
1 CI-V 1
2 MODPTT 9
3 NC —
4 NC —
5 NC —
6 AF OUT 3
D-sub 9 pin
(Female)
7 AF IN 2
D-sub 15 pin
(Male)
8 AF GND 4
9 GND 12
■ Connector information for OPC-2308
to IC-F8101 [ACC]
OPC-2308
D-sub 9 pin
(male)
D-sub 15 pin
(male)
D-sub 9 pin
(female)
