74
6
CONNECTION AND INSTALLATION
2001 NEW 2001 NEW
■ Connections
PC
to [USB]
to [ACC]
to a USB port
Supplied Ferrite EMI filter
OPC-2308
GPS unit
UX-248
GPS unit
D-sub 9 pin
(male)
D-sub 9 pin
(female)
D-sub 15 pin
(female)
Modem unit
to a 13.8 V DC power source
Transceiver
USB cable
(purchase separately)
+ red
_ black
12V
Battery
12V
Battery
R WARNING! NEVER remove
the fuse holders from the black
and red cables.
NEVER remove this
Ferrite EMI filter.
NEVER turn these
connector screws.
Only for USA versions
R WARNING! NEVER
connect to a 24 V bat-
tery. This will damage
the transceiver.
Wrap the connectors with rubber vulcanizing tape,
and then wrap electrical tape over the rubber vul-
canizing tape to help in waterproofing.
11
6
10
15
1 5
12
to IC-F8101
SP connector
AF input
FSK terminal unit
AF ground
Ground
To pin 9
To pin 10
To pin 12
• FSK connection
[ACC]
FSK keying
Tx/Rx control
11
6
15
1 5
To pin 12
To pin 10
• CW key connection
[ACC]
To Next Page
