Icom IC-FR4000 Series User Manual

Duplexer and Isolator Installation
(Reference only)
Band Model No. Descriptions
VHF
MPX2/6LN-4/6 Frequency range 138-156MHz, duplex spacing range 4-6MHz
MPX2/6LN-6/15 Frequency range 138-156MHz, duplex spacing range 6-16MHz
MPX2/6HN-4/6 Frequency range 152-175MHz, duplex spacing range 4-6MHz
MPX2/6HN-6/15 Frequency range 152-175MHz, duplex spacing range 6-16MHz
UHF
MPX70/6LN-5/7 Frequency range 406-440MHz, duplex spacing range 5-7MHz
MPX70/6LN-7/9 Frequency range 406-440MHz, duplex spacing range 7-9MHz
MPX70/6LN-9/13 Frequency range 406-440MHz, duplex spacing range 9-13MHz
MPX70/6LN-13/16 Frequency range 406-440MHz, duplex spacing range 13-16MHz
MPX70/6HN-5/7 Frequency range 430-470MHz, duplex spacing range 5-7MHz
MPX70/6HN-7/9 Frequency range 430-470MHz, duplex spacing range 7-9MHz
MPX70/6HN-9/13 Frequency range 430-470MHz, duplex spacing range 9-13MHz
MPX70/6HN-13/16 Frequency range 430-470MHz, duplex spacing range 13-16MHz
Band Model No. Descriptions
VHF
636-6A-1-2 Frequency range 144-154MHz, duplex spacing range 4.5MHz
636
-
6A
-
2
-
2
Frequency range 154
-
164MHz, duplex spacing range 4.5MHz
PROCOM
PROCOMPROCOM
PROCOM (www.procom-dk.com)
Radio Frequency Systems
Radio Frequency Systems Radio Frequency Systems
Radio Frequency Systems (www.rfsworld.com)
 Duplexers
DuplexersDuplexers
Duplexers
The sample list of Duplexers and Isolators available in the market
The sample list of Duplexers and Isolators available in the marketThe sample list of Duplexers and Isolators available in the market
The sample list of Duplexers and Isolators available in the market
26
VHF
636
-
6A
-
2
-
2
Frequency range 154
-
164MHz, duplex spacing range 4.5MHz
636-6A-3-2 Frequency range 164-174MHz, duplex spacing range 4.5MHz
UHF
633-6A-1N Frequency range 406-450MHz, duplex spacing range 5MHz
633-6A-2N Frequency range 450-470MHz, duplex spacing range 5MHz
633-6A-5N Frequency range 406-450MHz, duplex spacing range 10MHz
633-6A-6N Frequency range 450-470MHz, duplex spacing range 10MHz
633-6A-7N Frequency range 470-512MHz, duplex spacing range 10MHz
633-6A-8N Frequency range 355-406MHz, duplex spacing range 10MHz
633-6A-9N Frequency range 470-512MHz, duplex spacing range 3MHz
 Isolators
IsolatorsIsolators
Isolators
Sinclair
Sinclair Sinclair
Sinclair (www.sinclairtechnologies.com
)
Band Model No. Descriptions
VHF
I2113A 132–174MHz, 60 watt load, 125 watt input power, factory-tuned
I2113T 138–174MHz, 60 watt load, 125 watt input power, Field Tunable
UHF
I3113A 406-512MHz, 60 watt load, 125 watt input power, factory-tuned
I3113AT 406-430MHz, 60 watt load, 125 watt input power, Field Tunable
I3113AT 450-470MHz, 60 watt load, 125 watt input power, Field Tunable
Band Model No. Descriptions
VHF PRO-IS-150-S 145–175MHz, 150 watt input power, Field Tunable
UHF PRO-IS-450-S 400-470MHz, 125 watt input power, Field Tunable
PROCOM
PROCOMPROCOM
PROCOM (www.procom-dk.com)
