Icom IC-FR4000 Series User Manual

Common Features
Internal space for duplexer and isolator
Internal space for duplexer and isolatorInternal space for duplexer and isolator
Internal space for duplexer and isolator
The repeater has an internal space to install a
duplexer and isolator*. The controls of the duplexer
are accessible from the front of the repeater without
disassembly. Faster and easier maintenance and
adjustment is possible.
*Ask your dealer for details about available duplexers and
isolators.
16
1616
16-
--
-digit alphanumeric display
digit alphanumeric displaydigit alphanumeric display
digit alphanumeric display
The 16-digit alphanumeric LCD displays channel
number, channel name, decoded ID (with 2-Tone and
DTMF), etc. Great for use as a base station.
Telephone interconnect capability
Telephone interconnect capabilityTelephone interconnect capability
Telephone interconnect capability
The repeater has a 4-pin modular connector allowing
telephone interconnection.
DTMF remote control capability
DTMF remote control capabilityDTMF remote control capability
DTMF remote control capability
You can control the repeater from a remote location
over the air or over a phone line with DTMF.
Programmable key assign function
Programmable key assign functionProgrammable key assign function
Programmable key assign function
The following functions can be assigned to the [PROG]
button.
• Priority A • Priority A (Rewrite)
ADDITIONAL FEATURES
ADDITIONAL FEATURESADDITIONAL FEATURES
ADDITIONAL FEATURES
• Self check function checks for internal errors and
alerts with a beep sound or with a phone call
• Compatible with VEGA tone remote control system
• CW ID transmitter (DTMF or 5-Tone also selectable)
• Password and kill/stun function for security
All trademarks are the properties of their respective holders.
7
• Priority A • Priority A (Rewrite)
• Display select • Lock
• High/Low • Wide/Narrow
• Call • Call A, B (PMR mode only)
• Emergency Single • Emergency Repeat
• Scrambler • Special Function 1, 2
• Null
Wall or rack mount available
Wall or rack mount availableWall or rack mount available
Wall or rack mount available
With an optional microphone, the repeater can be
placed on a desktop as a base station. The optional
MB-77 wall mount bracket allows you to set the
repeater on a wall. A 19" 3U height rack mount
bracket, MB-78, is also available.
19-inch rack mount, MB-78 Installation on a wall with the MB-77
Standard
MIL 810C MIL 810D MIL 810E MIL 810F
Method Proc. Method Proc. Method Proc. Method Proc.
High Temp. 501.1 I 501.2 I, II 501.3 I, II 501.4 I, II
Low Temp. 502.1 I 502.2 I, II 502.3 I, II 502.4-3 I, II
Vibration 514.2 VIII, X 514.3 I 514.4 I 514.5 I
Shock 516.2 I 516.3 I 516.4 I 516.5 I
Applicable U.S. Military Specifications
Applicable U.S. Military SpecificationsApplicable U.S. Military Specifications
Applicable U.S. Military Specifications
The MIL
MILMIL
MIL-
--
-STD
STDSTD
STD-
--
-810
810810
810 series of standards are issued by the
United States Army's Developmental Test Command,
to specify various environmental tests to prove that
equipment qualified to the standard will survive in the
field.
Icom
Icom Icom
Icom makes rugged products
that have been tested to and
passed the following MIL-STD
requirements and strict
environmental standards.
