PANELDESCRIPTION
1
New2001
ePTTSWITCH[PTT] (p. 38)
Hold down to transmit, release to receive.
For ID-51E only
Push briefly and release, then hold down to transmit a
1750 Hz tone burst.
rCD (RX CALL SIGN DISPLAY)/D-PAD (LEFT) KEY
[CD]/D-pad()
➥ While in the DV mode, hold down for 1 second
to open the received calls record. (p. 51)
➥ While in the DR screen, or with the Menu screen
orQuickMenuscreenopens,pushtoselectan
upper tier menu.
tSQUELCHKEY[SQL]
Hold down to temporarily open the squelch and monitor ➥
the operating frequency.
While holding down this key, rotate ➥ [DIAL] to adjust the
squelch level. (p. 35)
y POWERKEY[
]
Hold down for 1 second to turn the transceiver power ON
or OFF. (p. 11)
uMENU•LOCKKEY[MENU
]
➥ Push to enter or exit the Menu screen. (p. 19)
➥ Hold down for 1 second to toggle the Key Lock
function ON or OFF. (p. 37)
■ Front,topandsidepanels
q
w
r
u
i
o
!0
e
t
y
!1
!2
!3
!4
!5
!6
!7
!8
!9
@0
@1
@2
Function
display (p. 5)
Internal
microphone
Speaker
q ANTENNA CONNECTOR
Connect the antenna here.
 •The optional AD-92SMA adapter connects an antenna
with a BNC connector.
w TX/RXINDICATOR[TX/RX] (p. 38)
Lights green while receiving a signal or when the squelch
is open, lights red while transmitting.
