Icom ID-51A Basic Instructions

New2001
4
1
PANEL DESCRIPTION
1
@1 VOLUMECONTROL[VOL]
Rotate to adjust the audio volume level. (p. 11)
@2CONTROLDIAL[DIAL]
Rotate to select the operating frequency. (p. 34) ➥
While in the Memory mode, rotate to select a memory ➥
channel. (p. 42)
While scanning, rotate to change the scanning direc- ➥
tion.
Holddown[SQL],androtatetoadjustthesquelchlevel. ➥
(p. 35)
While in the DR screen, or with the Menu screen or ➥
QuickMenuscreenopen,rotatetoselectadesiredop-
tion or value.
D QuickMenu
IntheQuickMenu,theselectableitemsdiffer,dependingon
the operating mode or function. The items shown below are
examples.
VFOmode MRmode CALL-CHmode DRfunction
Band Select Bank Select DUP Group Select
DUP DUP TONE
Repeater Detail
TONE TONE TS DTMF TX
TS TS DTMF TX Voice TX
DTMF TX SKIP Voice TX
GPS Information
Voice TX DTMF TX GPS Information GPS Position
GPS Information Voice TX GPS Position PRIO Watch
GPS Position
GPS Information PRIO Watch Weather Alert
PRIO Watch GPS Position Weather Alert Display Type
Weather Alert PRIO Watch Display Type DSQL
Home CH Set Weather Alert Voltage Home CH Set
Voltage Home CH Set Band scope Voltage
Band scope Display Type
<<REC Start>> Band scope
<<REC Start>> Voltage <<BC Radio ON>> <<REC Start>>
<<BC Radio ON>> Band scope <<BC Radio Mode>> <<BC Radio ON>>
<<BC Radio Mode>> <<REC Start>> <<GPS Logger only>> <<BC Radio Mode>>
<<GPS Logger only>> <<BC Radio ON>> <<GPS Logger only>>
<<BC Radio Mode>>
<<GPS Logger only>>
PANEL DESCRIPTION
