Icom ID-51A Basic Instructions

27
3
MENU SCREEN
New2001 New2001
DataSpeed
Selects the data transmission speed for low-speed com-
munication,orbetweenthe[DATA]jackandexternalmod-
ules like a GPS receiver, and so on.
VOX
VOX
Turns the VOX function ON or OFF.
VOXLevel
Sets the VOX gain level.
VOXDelay
Sets the VOX Delay time.
VOXTime-OutTimer
Sets the VOX Time-Out Timer to prevent an accidental
prolonged transmission.
HeadsetSelect
Selects the headset type to be used for the VOX func-
tion to limit the maximum audio output level to protect the
headset speaker.
CI-V
Set CI-V options.
CI-V (DATAJack)
Selectswhetherornottousethe[DATA]jacktocontrol
an external device.
CI-VAddress
Sets the transceiver’s unique CI-V hexadecimal address
code.
Menu items and their details ■
Root item “Function” (Continued)
RemoteMICKey
The function assignments for keys on the optional HM-
75LS can be changed for simple remote control operation.
DuringRX/Standby
Selects the key function to be used while receiving or in
the standby mode.
DuringTX
Selects the key function to be used while transmitting.
KeyLock
Selects the key lock type when the Key Lock function is
turned ON.
PTTLock
Turns the PTT Lock function ON or OFF.
BusyLockout
Turns the Busy Lockout function ON or OFF.
Time-OutTimer
Selects the Time-Out Timer time options.
ActiveBand
Allows
continuous frequency selection across all bands by
rotating[DIAL].
MICGain(Internal)
Sets the internal microphone sensitivity to suit your prefer-
ence.
MICGain(External)
Sets the external microphone sensitivity to suit your prefer-
ence.
