Intel Desktop Board D850GB/D850GBAL Product Guide
28
Installing the Processor Retention Mechanisms
To install the processor retention mechanisms (RM), follow these instructions:
1. Locate the processor RM holes as seen in Figure 10.
OM10644
Figure 10. Location of the Processor RM Mounting Holes
