Intel Desktop Board D850GB/D850GBAL Product Guide
74
Front Panel Connectors
Figure 26 shows the location of the front panel connectors.
OM10665
BA
1
10
7
2
1
15
2
1
16
1
DC
Item Description
A
B
C
D
SCSI LED
Front panel USB
Auxiliary front panel power LED
Front panel
Figure 26. Front Panel Connectors
