Installing and Replacing Desktop Board Components
33
4. Connect the processor fan cable to the processor fan connector (see Figure 16).
OM10661
Figure 16. Connecting the Processor Fan Cable to the Processor Fan Connector
Removing a Processor
To remove a processor, follow these instructions:
1. Observe the precautions in “Before You Begin” (see page 21).
2. Disconnect the processor fan cable.
3. Detach the fan heatsink clips.
4. Raise the socket lever completely.
5. Remove the processor and fan heatsink.
