79
A Error Messages and Indicators
The D850GB/D850GBAL board reports POST errors in three ways:
• By sounding a beep code
• By lighting the enhanced diagnostic LEDs
• By displaying an error message on the monitor
BIOS Beep Codes
The BIOS beep codes are listed in Table 29. The BIOS also issues a beep code (one long tone
followed by two short tones) during POST if the video configuration fails (a faulty video card or
no card installed) or if an external ROM module does not properly checksum to zero.
Table 29. Beep Codes
Number of Beeps Description
1 Refresh failure
2 Parity cannot be reset
3 First 64 K memory failure
4 Timer not operational
5 Processor failure (Reserved; not used)
6 8042 GateA20 cannot be toggled (memory failure or not present)
7 Exception interrupt error
8 Display memory R/W error
9 (Reserved; not used)
10 CMOS Shutdown register test error
11 Invalid BIOS (such as, POST module not found)
