ARMY TM 9-2815-254-24
AIR FORCE TO 38G1-94-2
ac.
Install oil pump, refer to paragraph 3-18.3.
ad.
Install crankcase, refer to paragraph 3-29.3.
ae.
Install cylinder head, refer to paragraph 3-27.6.
af.
Install fuel injection pump, refer to paragraph 3-11.6.
ag.
Install idler gear and shaft, refer to paragraph 3-30.5.
ah.
Install front cover, refer to paragraph 3-25.3.
ai.
Install oil pan, refer to paragraph 3-17.3.
aj.
Install PCV system, refer to paragraph 3-20.3.
ak.
Install water pump, refer to paragraph 3-7.4.
al.
Install alternator, refer to paragraph 3-24.6.
am. Install starter, refer to paragraph 3-23.6.
an.
Install fuel filter assembly, refer to paragraph 3-9.4.
ao.
Install oil filter, refer to paragraph 3-14.3.
3-29.
CRANKCASE.
3-29.1.
Removal.
a.
Remove oil pan, refer to paragraph 3-17.1.
b.
Remove two screws (1, FIGURE 3-98) securing crankcase to flywheel housing.
C.
Remove two bolts (2) two bolts (3) two screws (4) and fourteen screws (5) securing crankcase
(6) to engine block.
d.
Remove crankcase (6) from engine block using a screwdriver or pry bar in slit provided on
crankcase mounting flange. Remove two shims (7).
3-29.2. Inspection.
a.
Inspect crankcase for cracks, deformities, or other damage. If found, replace crankcase.
b.
Remove any traces of sealing compound (FORMAGASKET2) from mating surfaces of crankcase
and engine block.
3-148 Change 2
