ARMY TM 9-2815-254-24
AIR FORCE TO 38G1-94-2
e. Position basic flywheel (6) on crankshaft, aligning dowel pin.
f. Coat threads of six flywheel attaching bolts (4) with engine lubricating oil (ML-L-2104).
g. Install flywheel washer (5) on crankshaft and install six bolts (4). Tighten bolts to 79.5 ft-lbs (107.9 Nm) in
sequence shown in FIGURE 3-110.
NOTE
Use a block of hard wood to prevent flywheel from turning while tighten bolts.
h. Position flywheel assembly (3) on basic flywheel (6) and secure with four bolts (1) and washers (2).
i. Install starter, refer to paragraph 3-23.6.
FIGURE 3-110. Flywheel Bolt Tightening Sequence
3-32. CYCLINDER BLOCK ASSEMBLY.
3-32.1. Disassembly.
a. Remove crankshaft, refer to paragraph 3-28.1.
b. Remove bolts (1, FIGURE 3-111) and washers (2) securing left engine foot (3) to cylinder block; remove foot.
3-162
