Position filter assembly on mounting bracket and secure filter body (15) with two bolts (14). Do not tighten
bolts until fuel tubes have been connected to filter and tightened.
Remove caps and install fuel return line (10).
Attach fuel tube (13) to fitting on top of filter body (15) with two new seals (12) and fluid passage bolt (11).
Tighten fluid passage bolt (11) to 132 in-lbs (14.9 Nm).
Remove caps and attach fuel tube (9) to fluid passage bolt (11) with two new seals (8) and fluid passage bolt
(7).
Remove caps and connect fuel line to fitting (25) on side of filter body (15).
If removed from fuel injection pump, remove caps and attach one end of fuel tube (4) to pump with two new
seals (6) and fluid passage bolt (5).
Attach other end of fuel tube (4) to top center fitting of filter body (15) with two new seals (3) and fluid passage
bolt (2).
Tighten fluid passage bolts (2, 5, 7, and 11) to 132 in-lbs (14.9 Nm).
Tighten filter mounting bolts (14).
Ensure filter drain plug (1) is tight.
Bleed engine fuel system, refer to paragraph 3-12.
Operate engine and check for leaks.
3-10. FUEL lNJECTORS AND PIPING.
3-10.1. Removal.
Fuel is flammable. Keep fuel away from heat and open flame. Failure
to observe this warning could result in serious injury or death.
