ARMY TM 9-2815-254-24
AIR FORCE TO 38G1-94-2
FIGURE 3-99. Crankcase Fastener Tightening Sequence
3-30. CAMSHAFT AND IDLELR GEAR ASSEMBLIES.
3-30.1. Removal.
a. Remove oil filter, refer to paragraph 3-14.2.
b. Remove fuel fitter, refer to paragraph 3-9.1.
c. Remove starter, refer to paragraph 3-23.1.
d. Remove attemator, refer to paragraph 3-24.1.
e. Remove water pump, refer to paragraph 3-7.1.
f. Remove PCV system, refer to paragraph 3-20.1.
g. Remove oil pan, refer to paragraph 3-17.1.
h. Remove front gear cover, refer to paragraph 325.1.
i.
Measure timing gear backlash (refer to FIGURE 3-100) as follows:
(1) Set a dial indicator on timing gear to be measured.
3-150
