en 44
6 OPERATION
mark two or three inches (51 or 76mm) in from the outer edges of the two front grass catchers will help
align each overlapping pass).
4. After all of the straight passes have been made, make one final pass around the outer edge of the green.
This final pass should always be in the opposite direction from the last time the green was mowed.
5. With the engine stopped or the reel enable switch in the "OFF" position, empty the grass catchers before
proceeding to the next green.
6.12 HOW TO STOP THE ENGINE_____________________________________________
1. Disengage drive to the Cutting Units with the Cutting Unit Switch.
2. Return the FWD/REV pedal to the neutral position.
3. Set the parking brake.
4. Move the throttle control lever to the SLOW position.
5. Turn the ignition key to OFF
6.13 HOW TO REMOVE A BLOCKAGE FROM CUTTING UNITS ____________________
1. Disengage the power to the cutting units with the cutting unit switch.
2. Keep the cutting units lowered to the ground (Wait for the remaining cutting cylinders to stop rotation).
3. Lift the cutting units into the “Transport Position”, lock in position use the transport latches fitted on your product.
4. Remove your foot from the forward/reverse pedal.
5. Set the parking brake.
6. Move the throttle control lever to the slow position.
7. Turn the ignition key to the off position and remove the key
NOTICE
To avoid damage to the green, NEVER stop the forward motion of the mower on the green with the reels
turning. Stopping the mower on a wet green may cause wheel indentations.
CAUTION
It is important to note: there will be remaining hydraulic pressure within the system that can cause
the cutting cylinder to rotate when the obstruction is removed. Therefore keep your hands, feet
and clothing away from Cutting Units at all times.
NOTICE
Make sure correctly selected PPE is worn before you clear the obstruction.
!
