91
QUA
L
ITY OF CUT 11
1
1
.
9 TORN CROWNS
____________________________________
_________________
“T
orn Crowns”
Th
is
problem
is identified
when clumps
of grass (Crowns) are torn up rather than cut
.
Possible Cause
Correction
T
oo much material.
Cut more frequently, increase HOC.
Worn blade
edge.
Sharpen or Replace damaged blades.
Cutting too fast for conditions.
Decrease the cutting speed.
TN1234
92
94
