MAINTENANCE 7
7.13 HANDBRAKE _______________________________________________________
Place the front axle on axle stands and remove the front wheels. Inspect the discs and pads for wear and replace
if necessary. Remove all debris from around the brake assembly and ensure the calliper is free to float.
To Adjust
a. Release locknut's A.
b. Adjust cable until 1mm of movement is obtained at caliper lever B when the hand brake is NOT applied.
c. Adjust both brake calipers equally.
d. Tighten nuts A.
e. Check hand brake operation. The hand brake lever should
raise between eight and eleven clicks on the ratchet with a
force of 33kgf
7.14 TYRES _____________________________________________________________
Keep tyres properly inflated to prolong tire life. Check inflation pressure while the tyres are cool. Use an accurate,
low pressure tyre gauge.
Keep tires inflated to the air pressure specified. See Specifications 3.2
CAUTION
Caution must be used when inflating a low pressure tyre to the recommended pressure. Check pressure
with a low pressure tyre gauge before connecting an air hose to a partly inflated tyre.
Due to the low air volume requirements of a small tyre, over inflation may be reached in a matter of a few
seconds, which could cause the tyre to explode.
!
