20 - 1
Steering System - Bleeding
Whenever any hydraulic steering component is
disconnected or removed the system must be bled as
follows.
With the engine running, the following procedure must be
carried out in the correct order that is laid down. You must
not alter the order of selections and operations.
1 Select 2 Wheel Steer
(a) Turn steering wheel to left, until front wheels are
fully locked to the left.
(b) Turn steering wheel to right, until front wheels are
fully locked to the right.
2 Select 4 Wheel Steer
(a) Turn steering wheel to left, until front wheels are
fully locked to the left.
3 Select 2 Wheel Steer
(a) Turn steering wheel to full right lock.
(b) Turn steering wheel to full left lock.
(c) Turn steering wheel to full right lock.
4 Select 4 Wheel Steer
(a) Turn steering wheel to left, until the front wheels
are fully locked to the left.
5 Select 2 Wheel Steer
(a) Turn steering wheel to full right lock.
(b) Turn steering wheel to full left lock.
(c) Turn steering wheel to full right lock.
6 Select 4 Wheel Steer
(a) Turn steering wheel to left, until front wheels are
fully locked to the left.
7 Select 2 Wheel Steer
(a) Turn steering wheel to full right lock.
(b) Turn steering wheel to full left lock.
(c) Turn steering wheel to full right lock.
8 Select 4 Wheel Steer
(a) Turn steering wheel to left, until the front and rear
wheels are fully locked.
Section H Steering
9803/3280
Section H
20 - 1
Issue 1
Service Procedures
