ICB E RROR C ODES
ICB LED Flash Error Codes shown in Table 15 are related to the Intelligent
Cash Box (ICB) system, and are indicated by the Bezel LED flashing a
RED
color. Count the number of Flashes between pauses to identify the Error,
Causes and Solutions.
Table 15 ICB LED Error Codes
Online Offline
Error Causes and Solutions
LED Color
Flash
Sequence
LED Color
Flash
Sequence
13 13
ICB
Communications
(1)
During ICB Communication, Data Errors are occurring.
[Solution] Check ICB Settings and reseat the Cash Box. Clean
the Unit.
[Relative Part] ICB Board
If the condition is not resolved, change the above related part.
26 OFF
Incorrect ICB
Settings
During startup, the ICB function is disabled and an ICB-
enabled Cash Box is inserted.
[Solution] Ensure that ICB is enabled. Clean the ICB Sensors.
[Relative Part] CPU Board
If the condition is not resolved, change the above related part.
27 OFF
ICB
Communications
(2)
During startup, ICB is not communicating.
[Solution] Check for proper ICB settings. Clean the ICB
Sensors.
[Relative Part] ICB Circuit Board, ICB Sensors, ICB Cash Box
Module
If the condition is not resolved, change the above related part
or parts.
28 OFF ICB Checksum
During startup, the ICB data is not correct.
[Solution] Initialize the ICB enabled Cash Box by redocking on
a Read/Write Tool.
[Relative Part] CPU Board, ICB Cash Box Module
If the condition is not resolved, change the above related part
or parts.
29 OFF ICB Number
During startup, there is a mismatch between the TBV Machine
Number and the Cash Box Machine Number.
[Solution] Install a properly initialized Cash Box.
[Relative Part] CPU Board, ICB Cash Box Module
If the condition is not resolved, change the above related part
or parts.
30 OFF ICB Initialization
The ICB Cash Box has not been initialized.
[Solution] Dock the ICB Cash Box on a Read/Write Tool to
initialize it.
[Relative Part] CPU Board, ICB Cash Box Module
If the condition is not resolved, change the above related part
or parts.
31 OFF ICB Module
During ICB Communication, the ICB enabled Cash Box was
removed.
[Solution] Check ICB Settings and reseat the Cash Box.
[Relative Part] Cash Box Sensor, ICB Cash Box Module
If the condition is not resolved, change the above related part
or parts.
