JCM TBV Series User Manual

Part No. 960-100941R_Rev. A © 2016 JCM American Corporation
35
TBV Transaction Based Validator JCM® Training Overview October, 2016
C ALIBRATION E RRORS
Tables 18, 19 and 20 provide information about Calibration Error Codes.
These errors are divided into functions:
• UV Sensor Errors (refer to Table 18) are 8 digits, starting with 03, 04 or 06;
• String Detection Sensor Errors (refer to Table 18) are 8 digits, starting with 08;
• Bar Code Errors (refer to Table 19) are 8 digits, starting with 07;
• Positioning Sensor Errors (refer to Table 19) are 8 digits, starting with 09;
• Validation Sensor Errors (refer to Table 20) are 18 digits.
Table 18 Sensor Calibration Error Code Format
Sensor Calibration Digit Number Error Code Format
Validation Sensor [D/A Value, non-paper] 18 digits 01-YYYY-YYYY-YYYY-YYYY*
* Refer to Table 19 for Sensor Flag Values indicated in the “zz-zz-zz” format.
Validation Sensor [with the Reference paper] 18 digits 03-YYYY-YYYY-YYYY-YYYY*
Validation Sensor [non-paper] 18 digits 05-YYYY-YYYY-YYYY-YYYY*
UV [Reflection] Sensor with paper 8 digits 03-000-000
UV [Transmissive] Sensor with paper 8 digits 04-000-000
UV [Transmissive] Sensor non-paper 8 digits 06-000-000
Bar Sensor 8 digits 07-zz-zz-zz†
† Refer to Table 20 for Sensor Flag Values indicated in the “YYYY-YYYY-YYYY-YYYY” format.
String Detection Sensor 8 digits 08-zz-zz-zz†
Positioning Sensor 8 digits 09-zz-zz-zz†
Table 19 Sensor Flag Values
(Bar Sensor or Positioning Sensor Calibration Error)
String Sensor Sensor Flag Value
INS Entrance Sensor 00-00-01
WID_PO Centering Sensor 00-00-02
FEEDOUT Feed Out Sensor 00-00-04
STK_POS Box Feed Out Sensor 00-00-08
BOX_FUL Box Full Sensor 00-00-10
BOX_NFUL Box Near Full Sensor 00-00-20
STK_HOM Pusher Plate Home Position Sensor 00-00-40
STK_HAF Pusher Plate Half-way Position Sensor 00-00-80
BOX_IN Box Sensor 00-01-00
WID_HOM Centering Mechanism Home Position Sensor 00-02-00
GS_INS_L Shutter Unit Home Positioning Sensor (left) 00-04-00
GS_INS_R Shutter Unit Home Positioning Sensor (right) 00-08-00
BOX_LOK Box Lock Sensor 00-10-00
GS_HOME Shutter Unit Home Positioning Sensor 00-20-00
BNF_INS BNF Entrance Sensor 01-00-00
BNF_MID BNF Assignation Sensor 02-00-00
BNF_REJ BNF Reject Sensor 04-00-00
BAR Bar Sensor 10-00-00
