JCM TBV Series User Manual

Part No. 960-100941R_Rev. A © 2016 JCM American Corporation
37
Lecture Notes
TBV Transaction Based Validator JCM® Training Overview October, 2016
TBV MAINTENANCE EQUIPMENT
Maintenance Equipment required to test a TBV Transaction Based Validator
Unit is shown in Figure 15 and listed in Table 21 on page 38.
a
b
c
d
1
e
f
g
d
2
h
j
k
l
i
Only the European
Connector Version is
shown here. Order the
“JAC No.” to obtain the
USA Style AC Wall Plug.
Figure 15 TBV Maintenance Equipment Requirements

JCM TBV Series Specifications

General

Brand	JCM
Model	TBV Series
Category	Bank Note Validator
Language	English
