29
(3) Sewing operation
Operation example : After performing sewing with the contents of the registered P2, perform sewing with
the contents of P3.
1) Turn ON the power switch.
2) Press direct pattern .
3) Press READY key to light up SET READY
LED . Once the LED lights up, the work clamp
goes up after traveling.
4) Check the contour of the sewing pattern.
(Refer to the item
"I.5-4. Checking the contour
of a sewing pattern" p.20
.)
5) If the contour of the sewing pattern is acceptable,
the sewing can be made.
6) After the completion of sewing, press direct pat-
tern . Then, the work clamp comes down,
retrieves the origin, travels to the sewing starting
point and goes up. Then, the origin is retrieved.
After the origin retrieval, the work clamp travels to
the sewing starting point and goes up.(The P keys
can operate the pattern change by one-touch
even when the SET READY LED is lighting up.)
7) Perform the above items 4) and 5).
* P1 to P25 can be specified by selecting the
pattern. Display the target pattern using DATA
CHANGE key .
P1 to P25 which have not been registered are not
indicated.
Press P1 to P25 key while the SET
READY LED lights up and the presser
comes down. Be careful that your fin-
gers are not caught in the presser.
Pattern register from P26 to P50 can be
performed. Register can not be performed
in to key. Designate the pattern
by the pattern selection only. Indicate the
pattern with
key.
Pattern selection from P26 to P50 can-
not be performed while the SET READY
LED lights up.
0 to 200
P1 to 25
0 to 200
P1 to P25
P26 to P50
