3. INSTALLATION

3-1. Installing the electrical box

Install control box

󰿿

to the location illustrated in the

gure using four bolts

󱀀

, four plain washers

󱀁

and

four spring washers

󱀂

and four hexagonal nuts

󱀃

supplied with the unit.

Bolt

󱀀

is a cup head square neck bolt (M8;

Length: 70 mm) and nut

󱀃

is a hexagonal

nut (M8).

󰿿

󱀁

󱀂

󱀃

󰿿

󱀀

Install the pedal sensor

󰿿

to the table with mounting

screws

󱀀

supplied with the unit.

3-2. Installing the pedal sensor

󱀀
