– 20 –
13. TABLE OF SC-922 FUNCTION ITEMS IN ACCORDANCE WITH THE
ADDITIONAL DEVICES
Additional
device
Function
No.
Function item
Starting
level
Setting
range
Description
Applicable
model
2-pitch
device
148 2-pitch output during
reverse feed stitch-
ing at start or at end
User 0, 1 0 : Invalid
1 : 2-pitch is output during controlling
reverse feed stitching at start or end.
LU-2212N-7
LU-2220N-7
149 Inversion of 2-pitch
output during output-
ting alternate vertical
amount
User 0, 1 0 : Invalid
1 : State of 2-pitch output is inversely
output, synchronizing with alternate
vertical output.
150 2-pitch initial output User 0, 1, 2 0 : When the power is ON, reset is made
with the status of the previous power
OFF.
1 : When the power is ON, 2-pitch output
is turned OFF.
2 : When the power is ON, 2-pitch output
is turned ON.
Alternate
vertical
amount
change
device
144 Setting of number of
stitches of automatic
release of alternate
vertical output
User 0,
1 to 30
stitches
0 : Automatic release is invalid.
1 to 30 : Release of alternate vertical out-
put is automatically performed by
the number of stitches.
LU-1500N-7
LU-1520NC-7
LS-1342-7
DNU-1541-7
PLC-1700-7
LU-2200N-7
146 Selection of alternate
vertical output after
thread trimming
User 0, 1, 2 0 : Invalid
1 : Alternate vertical output is forcibly
turned OFF after thread trimming.
2 : Alternate vertical output is forcibly
turned ON after thread trimming.
147 Alternate vertical
initial output
User 0, 1, 2 0 : When the power is ON, reset is made
with the status of the previous power
OFF.
1 : When the power is ON, alternate verti-
cal output is turned OFF.
2 : When the power is ON, alternate verti-
cal output is turned ON.
Needle
thread
clamp
device
156 Selection of needle
thread clamp switch
function
User 0, 1, 2 0 : When the needle clamp switch is
turned ON, this function is enabled.
1 : Needle clamp function will be disabled.
2 : Needle clamp function is enabled forci-
bly.
LU-2220N-7
To Next Page
