CAUTION: If you meet strong resistance when attempting to seat the module using
the ejectors, remove it from the chassis, and confirm that the slot is designed to
hold the component. Also, be sure that you have aligned the left and right edges
in the correct matching tracks.
7. Insert the module into the midplane by simultaneously pressing both ejectors inward and exerting
forward pressure on the module. The small red release buttons should click into place.
8. Tighten the module's captive screws using a Phillips screwdriver.
NOTE: Tighten the captive screws completely before installing an adjacent module so that
proper electromagnetic interference (EMI) gasket compression occurs. Failure to do this can
make it difficult to install adjacent modules.
9. Go to “Cabling the CTP2000 Platform Overview” on page 108.
RELATED DOCUMENTATION
Removing a CTP Interface Module, Processor Module, or Clock Module | 96
CTP2000 T1/E1 Interface Module | 13
CTP2000 Clock Interface Modules | 27
Cabling the CTP2000 Platform Overview | 108
T1/E1 Interface Module Pinouts | 51
Removing a CTP Interface Module, Processor Module, or Clock Module
NOTE: We recommend that you issue the slot disable command from the CLI before removing
a line module.
96
