Table 13: CTP2000 FXS Connector Pinouts on the RTM (continued)
PinSignalSignalPin
34Port 8 TPort 8 R9
35Port 9 TPort 9 R10
36Port 10 TPort 10 R11
37Port 11 TPort 11 R12
38Port 12 TPort 12 R13
39Port 13 TPort 13 R14
40Port 14 TPort 14 R15
41Port 15 TPort 15 R16
42Port 16 TPort 16 R17
43Port 17 TPort 17 R18
44Port 18 TPort 18 R19
45Port 19 TPort 19 R20
46Port 20 TPort 20 R21
47Port 21 TPort 21 R22
48Port 22 TPort 22 R23
49Port 23 TPort 23 R24
FXO Connector Pinouts
The RTM for the CTP2000 2W-FXO interface module uses a RJ-21 25-pair Telco connector labeled A.
The A connector has 24 FXS ports.
FXO T is connected to FXS R; FXO T is connected to FXS T.
Table 14 on page 51 lists the RTM pinouts for the FXO module.
