Table 3-1

Summary of SCPI commands (Models 2001 and 2002 )

Command Description

FORMat command summary

:FORMat

:ELEMents <item list>

Command to specify data elements to send over the bus:

Specify data elements (READing, CHANnel, RNUMber, UNITs,

TIMEstamp, STATus).

ROUTe command summary

:ROUTe

:CLOSe <list>

:STATe?

:CLOSe? <list>

:OPEN <list>|ALL

:ALL

:OPEN? <list>

:SCAN

[:INTernal] <list>

:FUNCtion <list>, <function>

:LSELect <name>

Commands to control 2001-TCSCAN:

Close speciﬁed channels.

Query closed channels.

Query speciﬁed channels (1=closed, 0=open).

Open speciﬁed channels or all channels.

Open all channels.

Query speciﬁed channels (1=open, 0=closed).

Path to scan channels.

Conﬁgure internal scan list.

Assign function to speciﬁed channels (see NOTE at end of table).

Select scan list (INTernal, NONE).

SENSe command summary

[:SENSe[1]]

:FUNCtion <name>

:ALTernate [1]

:SAVe

:RECall

:TEMPerature

:TRANsducer <name>

:RTD

:TYPE <name>

:RZERo <NRf>

:ALPHa <NRf>

:BETA <NRf>

:DELTa <NRf>

:TCouple

:TYPE <name>

:RJUNctionX

:RSELect <name>

:SIMulated <n>

:REAL

:TCOefﬁcient <n>

:OFFSet <n>

:ACQuire

Commands to conﬁgure measurements:

Select function (‘TEMPerature’, ‘VOLTage:AC’, ‘VOLTage:DC’,

‘RESistance’, ‘FRESistance’, ‘FREQuency’).

Program alternate function.

Save alternate function.

Recall alternate function.

Path to conﬁgure temperature measurements:

Select transducer (RTD, FRTD, or TCouple).

Conﬁgure RTD temperature measurements:

Select RTD sensor type (PT100, D100, F100, PT3916, PT385

or USER).

Specify constant for USER type (0 to 1000).

Specify constant for USER type (0 to 0.01).

Specify constant for USER type (0 to 1.00).

Specify constant for USER type (0 to 5.00).

Conﬁgure thermocouple sensor.

Select thermocouple type (J,K,T,E,R,S, or B).

Conﬁgure reference junction; where X=1 for Model

2001-TCSCAN.

Select reference type (SIMulated or REAL).

Specify simulated temperature in˚C (0 to 50).

Conﬁgure real reference junction:

Specify temp coefﬁcient (-0.09999 to 0.09999).

Specify voltage coefﬁcient at 0˚C (-0.09999 to 0.09999).

Update reference temperature.
