In this section:

DMM measurement capabilities ............................................... 4-1

High-energy circuit safety precautions ..................................... 4-2

Performance considerations ..................................................... 4-2

System considerations ............................................................. 4-6

Voltage measurements (DC volts and AC volts) ...................... 4-9

Current measurements (DC current and AC current) ............. 4-14

Resistance measurements ..................................................... 4-16

Temperature measurements .................................................. 4-22

Frequency and period measurements .................................... 4-41

Continuity testing .................................................................... 4-44

Refining measurements ......................................................... 4-47

DMM measurement capabilities

The DMM is not available on the Models 3706-S or 3706-SNFP.

The DMM of the Series 3700A can make the following measurements:

• DC voltage measurements from –10 nV to 300 V

• AC voltage measurements from 100 nV to 300 V

• DC current measurements from 1pA to 3.0 A

• AC current measurements from 1 nA to 3.0 A

• Two-wire resistance measurements from 1 µΩ to 120 MΩ

• Four-wire resistance measurements from 100 µΩ to 120 MΩ

• Commonside ohms resistance measurements from 1 µΩto 2 kΩ

• Frequency measurements from 3 Hz to 500 kHz

• Period measurements from 2 s to 330 ms

• Temperature measurements from –200 °C to 1820 °C

• Continuity testing using the 1 kΩ range

When using a switching module, do not exceed the maximum signal levels of the module.

For information on verification and calibration of the DMM, see Verification (on page B-1).

Section 4

Basic DMM operation

Keithley 3730 Reference Manual
