KERN PES 620-3M User Manual

21 TPES-B_TPEJ-B-BA-e-2319
7.4 Mains connection
Select the country-specific mains plug and insert it into the mains
adapter.
Check, whether the voltage acceptance on the scales is set correctly.
The balance may only be connected to the power supply, when the data
on the balance (sticker) and the local mains voltage are identical.
Only use KERN original mains adapters. Using other makes requires
consent by KERN.
Important:
➢ Prior to start-up check the mains cable for damages.
➢ Ensure that the mains adapter does not come into contact with
liquids.
➢ The mains plug must be accessible at any time.
7.4.1 Installation of the mains adapter
1. Place the country-specific power plug at a slight angle in the recess of
the mains adapter so that the spring points in the direction of the locking
arrow of the mains adapter.
2. Push the locking mechanism of the power plug downwards and press
the power plug into the recess of the mains adapter. Then release the
lock (make sure that the power plug is engaged).
Side view of the power plug (simplified):
Groove
Spring
