19.4 Formats of the data output (special format 1)
These data formats are only available for the PES weighing system.
19.4.1 Data composition
Consists of 14 characters, including the end characters (CR= 0DH, LF= 0AH) *.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
P1
Sp
D1
D2
D3
D4
D5
D6
D7
D8
Sp
U1
U2
U3
CR
LF
Polarity
Blank
Measurement data (incl. Decimal point)
Blank
Unit
End
characters
* End characters: CR = paragraph, LF = line
19.4.2 Data description
Presign:
P1 = 1 character
P1
Code
Significance
+
2BH
Data is 0 or positive
-
2DH
Data is negative
Numeric data:
(D1-D8):
Code
Significance
0 – 9
30H – 39H
Numbers 0 to 9
.
2EH
Decimal point (position not fixed)
Sp
20H
Space before numeric data
If numeric data does not contain a decimal
point, a space is output at the least significant
digit and no decimal point is output
/
2FH
Separator character inserted to the left of the
non-verification-relevant digit
*Sp = space
