DISASSEMBLY/REASSEMBLY
8
- 44 -
Timing angles for operation (0.15 valve play).
α = 6°beforeAcorrespondingto12mm
β = 22°after Bcorrespondingto44mm
γ =58°beforeBcorrespondingto116mm
δ =10°after Acorrespondingto20mm.
Valuesmeasuredonthecircumferenceofthe ywheel D = 230(one
degreecorrespondsto2mm).
α = 10°beforeAcorrespondingto20.09mm
β = 42°after Bcorrespondingto87.78mm
γ =58°beforeBcorrespondingto121.22mm
δ =10°after Acorrespondingto20.9mm.
Valuesmeasuredonthecircumferenceofthe ywheel D = 240(one
degreecorrespondsto2.09mm).
Timing angles for inspection (0.65-0.70 valve play).
α = 7°afterAcorrespondingto14mm
β = 9°after Bcorrespondingto18mm
γ =45°beforeBcorrespondingto90mm
δ =3°beforeAcorrespondingto6mm.
Valuesmeasuredonthecircumferenceofthe ywheel D = 230(one
degreecorrespondsto2mm).
α = 1°afterAcorrespondingto2.09mm
β = 31°after Bcorrespondingto64.79mm
γ =45°beforeBcorrespondingto94.05mm
δ =3°before Acorrespondingto6.27mm.
Valuesmeasuredonthecircumferenceofthe ywheel D = 240(one
degreecorrespondsto2.09mm).
KD 225_315_350_400_440 Workshop Manual_cod. ED0053029330_1° ed_ rev.00
For KD 225
For KD 315 - 350
For KD 225
For KD 315 - 350
