Fuel system
Removal
u Remove screws 7.
u Remove leakage-fuel detection block 5.
u Remove screws 4 .
u Remove retaining plate 3.
u Remove screws 2.
u Remove fuel return block 1.
Installation
u Install fuel return block 1 with screws 2.
u Install retaining plate 3 with screws 4.
u Install new screw plugs 6 (depending on application).
u Install leakage-fuel detection block 5 with screws 7.
u Tighten screws 2, 4, 7 to torque.
Specific values
Not applicable.
Tightening specifications
Refer to standard tightening torques. (For more information see: 5.3 Standard tightening torques,
page 264.)
3.6.7 Fuel pump HP and LP removal and installation (SL 250)
Previous tasks
q Close fuel supply.
q Release the pressure of the HP fuel system using Kodia tools.
q Remove fuel pipings connected to HP fuel pump.
Specific safety instructions
NOTICE
Risk of property damage by reuse of sealing.
Leakage by faulty seal.
u Replace all sealings.
130
© 2021 by Kohler Co. All rights reserved.
KD62V12 33525088601_7_1 EN_US
2021-07
