Service and Repair Manual Repair
Electrical system
3.11 Electrical system
3.11.1 Power take-off (PTO) and battery charging alternator removal and
installation (SL 223)
Previous tasks
q Remove battery charging alternator cover. (For more information see: 3.2.2 Battery charging
alternator & PTO cover removal and installation, page 61.)
Specific safety instructions
WARNING
Hazards by electrical shocks.
Contact with live conductor could result in death or serious injury.
u Access to live parts shall only be possible with voluntary action.
u Proceed to lock out and tag out prior to accessing to the engine.
u Respect the voltage indication of the engine’s technical data sheet.
u Check the grounding connection to avoid any risk of electrical arc.
u Observe the local safety regulations that apply to the machinery.
NOTICE
Risk of property damage by reuse of sealing.
Leakage by faulty seal.
u Replace all sealings.
Special tools
Special tool Designation
Pin for belt tensioner (x1)
Frequency meter
Tab. 53: Special tools
Consumables and equipment
– Vaseline
– Rags
– Belt tension frequency meter
KD62V12 33525088601_7_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
231
