Exhaust gas system
Tightening specifications
Fig. 177: Admission pipes
Reference
Key Screw specifications
Lubricant *
Reuse**
Torque Angle (°)
Step
± 5%
Step
± 5°
1 221AA EN 1664 M10x1,5-10.9-FLZN - Yes 1 35 Nm
26 ft-lb
- -
2 221AB EN 1665 M8x1.25x25-8.8-FLZN - Yes 1 25 Nm
18 ft-lb
- -
Tab. 37: Tightening specifications table
*Lubricants:
MG = Molykote G-n-plus
MW = Castrol Optimol paste white T
MH = Molykote HSC
O = Engine oil
XX = Loctite 243
YY = Loctite 577
**Refer to screws reuse rules. (For more information see: 5.3.2 Screws pre-tightening, reuse and
marking, page 264.)
3.8.2
Exhaust pipes to turbocharger removal and installation
Previous tasks
q Disconnect application set exhaust system.
156
© 2021 by Kohler Co. All rights reserved.
KD62V12 33525088601_7_1 EN_US
2021-07
