Cooling system
Installation
u Insert o-ring 7 and flange 6 on pipe from oil cooler casing.
u Mount pipe 14 with o-rings 3 on flange 6.
u Mount coolant pipeline 13 with o-ring 7 on flange 6.
u Insert guiding rods in coolant pump 9.
u Insert o-rings 10, 11, 12.
u Insert coolant pump HT 9.
u Tighten screws 1, 16 according to tightening specifications.
u Remove guiding rods.
u Tighten remaining screws 16 to torque.
u Assemble t-pipe 2, pipe 4 and flange 6 with o-rings 3, 7, 17.
u Position assembly with screws 1, 5 and tighten according to tightening specifications.
u Install test point fitting 8 on coolant pump.
Information
Vent coolant circuit at the end of installation.
Specific values
Not applicable.
Tightening specifications
Refer to standard tightening torques. (For more information see: 5.3 Standard tightening torques,
page 264.)
3.10.6 Coolant pump LT removal and installation (SL 215)
Previous tasks
q Drain LT coolant circuit.
q Remove machinery LT cooling system piping.
q Remove vibration damper cover. (For more information see: 3.2.1 Vibration damper cover
removal and installation, page 59.) .
q Remove battery charging alternator cover. (For more information see: 3.2.2 Battery charging
alternator & PTO cover removal and installation, page 61.)
Specific safety instructions
NOTICE
Risk of property damage by reuse of sealing.
Leakage by faulty seal.
u Replace all sealings.
222
© 2021 by Kohler Co. All rights reserved.
KD62V12 33525088601_7_1 EN_US
2021-07
