Appendix Operation and Maintenance Manual
Error code
8.2 Error code
Information
Error code list extracted from ECU software version 21.12.10 and dataset revision 9.
The following error code table is indicative. Refer to the technical data sheet of your engine for the
latest software version.
For further information, please contact your nearest authorized Kohler service representative.
Abbreviations:
– SPN - Suspect Parameter Number
– FMI - Failure mode identification
SPN FMI Designation
107 11 Air filter - Blocked / Clogged
516101 31 Air filter pressure switch - Supply voltage out of range
516428 31 Air pressure sensors - Plausibility error
108 31 Ambient pressure sensor - Supply voltage out of range
171 5 Ambient temperature sensor - Open circuit
171 3 Ambient temperature sensor - Short circuit to battery
171 4 Ambient temperature sensor - Short circuit to ground
171 31 Ambient temperature sensor - Supply voltage out of range
1176 1 Boost pressure - Pressure too high
1176 0 Boost pressure - Pressure too low
636 2 Camshaft position - Plausibility error
636 14 Camshaft position sensor - Ground error
636 5 Camshaft position sensor - Open circuit
636 3 Camshaft position sensor - Short circuit to battery
636 3 Camshaft position sensor - Short circuit to battery or open circuit
636 4 Camshaft position sensor - Short circuit to ground
636 31 Camshaft position sensor - Supply voltage out of range
157 0 Common rail - Critical overpressure
1239 2 Common rail - Leakage
157 15 Common rail - Overpressure warning
516117 11 Common rail - PCV opened due to overpressure
1075 2 Common rail - Plausibility error
516118 11 Common rail - Plausibility error of VCV current
516121 11 Common rail - Pressure remains above the set point
516122 11 Common rail - Pressure remains below the set point
516123 11 Common rail - Start pressure too low
146
© 2018 by Kohler Co. All rights reserved.
KD83V16 33521030601_0_1 EN_US
2018-07
