13-2
140-3 SERIES
DISASSEMBLY AND ASSEMBLY METHOD OF USING MANUAL
METHOD OF USING MANUAL
1. When removing or installing unit assemblies
1) When removing or installing a unit assembly, the order of work and techniques used are given for the
removal operation; the order of work for the installation operation is not given.
2) Any special techniques applying only to the installation procedure are marked , and the same mark
is placed after the relevant step in the removal procedure to indicate which step in the installation proce-
dure it applies to.
(Example)
REMOVAL OF ASSEMBLY.........................Title of operation
k
................................................................................Precautions related to safety when carrying out the
operation
1. X X X X (1) ..............................................................Step in operation
★ .............................................................................Technique or important point to remember when
removing XXXX (1).
2. (2):.......................................................... Indicates that a technique is listed for use dur-
ing installation
3. assembly (3)
6
......................................................................Quantity of oil or water drained
INSTALLATION OF ASSEMBLY .................Title of operation
• Carry out installation in the reverse order to removal.
..........................................................................Technique used during installation
★ .............................................................................Technique or important point to remember when
installing (2)
• Adding water, oil ...............................................Step in operation
★.......................................................................Point to remember when adding water or oil
5
..................................................................Quantity when filling with oil and water
2.
General precautions when carrying out installation or removal (disassembly or assembly) of units are given
together as PRECAUTIONS WHEN CARRYING OUT OPERATION, so be sure to follow these precautions
when carrying out the operation.
3. Listing of special tools
1) For details of the description, part number, and quantity of any tools (
A1
, etc.) that appear in the opera-
tion procedure, see the SPECIAL TOOLS LIST given in this manual.
To Next Page
